WS 98 Wall-Mount Sampler

SKU: 128 Category:

Introduction

The WS 98 is a compact sampler for indoor applications that do not require cooling. It features the same range of functions as larger, stationary samplers.

Programmable operation with respect to sampling rate, events etc. Sampler can be combined with an x-y distributor for separate samples

Features

  • Cost-effective simple operation
  • Housing made of high-value 316Ti stainless steel as standard;
  • well suited for use in demanding environments
  • Compatible with all WaterSam sampling systems
  • Suitable for refitting existing samplers (including those from
  • other manufacturers); optionally with connections such as cooling, etc.
  • Can be combined with a commercially available refrigerator for
  • low-cost cooling of composite samples
  • Optional XY Distributor in a support frame for discrete sample distribution
  • to a variety of bottle combinations
  • Optional rinsing of complete sampling line with clean water


Measures

Two separate composite samples collected from separate streams.



Additional information

Dimensions

H x B x T: 340 x 472 x 190 mm

Weight

Approx. 12 kg (depending on equip)

Housing

Stainless steel 316Ti

Sampling System

VAC vacuum pump system

Metering Glass

DURAN 50 borosilicate glass

Sample Volumes

15-350 ml (optional: up to 1000 ml)
